Solar Panel CSSB 120W 200W 300W 400W

Advanced energy storage product engineered for reliable power applications, scalable supply, and global B2B project requirements.

Model:: Solar Panel CSSB 120W 200W 300W 400W
Brand:: VoltCrave

Talk to Our Energy Storage Team

Portable Solar Power for RV & Outdoor Use

This foldable solar panel delivers convenient renewable energy for RV travel, camping, and off-grid applications. Its portable design supports quick setup and efficient solar charging for power stations, inverters, laptops, and other outdoor electrical devices.

MODEL	CSSB-120W	CSSB-200W	CSSB-300W	CSSB-400W
ELECTRICAL SPECIFICATIONS
Maximum Output Power (Pmax)	120W	200W	300W	400W
Operating Voltage (Vmp)	20V	20V	37V	35V
Operating Current (Imp)	6A	10A	8.11A	11.43A
Open Circuit Voltage (Voc)	23.6V	23.6V	43.66V	41.3V
Short-Circuit Current (Isc)	6.6A	11A	8.92A	15.57A
Module Efficiency	23%
Solar Cell Type	Monocrystalline
Waterproof / Dustproof Rating	IP64
OUTPUT CONNECTOR
Connection	MC4
Cable Length	Approx. 1m	Approx. 1m	Approx. 2m	Approx. 2m
DIMENSIONS & WEIGHT
Folded Size (mm)	381 × 381 × 50	400 × 400 × 55	480 × 480 × 60	600 × 490 × 60
Unfolded Size (mm)	1340 × 757	1410 × 1135	1700 × 1415	2135 × 1450
Net Weight	3.55kg	5.3kg	7.5kg	9.8kg
PACKAGING SPECIFICATIONS
Pieces per Carton	5 PCS	3 PCS	2 PCS	2 PCS
Carton Dimensions (cm)	42 × 38 × 42.5	42 × 26.5 × 44.5	52.5 × 17 × 54.5	64.5 × 16 × 54.5
Carton Weight	20.2kg	17.8kg	17.5kg	22.5kg
ACCESSORIES
Included Accessories	1m Wiring Cable with Multiple Connectors (MC4 to DC5521 / DC7909 / Anderson / XT60)
